DPS 850 Series is the power system playing the leader role in wire and wireless network application.
To maintain all aspects of the power performance at high level, Delta DPS 850 Series is featured with the high cost-performance ratio and gorgeous efficiency all rolled into one, that is, your one of a kind energy core.
Relying on the advanced controller, flexible PDUs and outstanding rectifiers providing power for 48 V system can reach each full potential in a compact 1U shelf.
Product Introduction
Features & Benefits
Perfect Integration with Delta Outdoor Enclosure
Compact Design 1U System
Applications
3G / 4G / 5G
Fixed Line
Datacom
Specifications
Input Voltage (nominal): Single phase; 100–240 VAC; 3 W (L, N, PE)
Input Voltage (range): 90–300 VAC; De-rating ≤ 184 VAC
Frequency: 45–66 Hz
Output Voltage (nominal): -48 VDC
Output Voltage (default): -54 VDC
Output Voltage (adjustable range): -42 to -58 VDC
Maximum Power @ nominal Input: 2.55 kW
Dimensions (W x H x D): 437.4 x 43.4 x 270 mm (17.2 x 1.7 x 10.6 in)
Weight: approx. 4.2 kg (9.3 Ib)
Operating Temperature: -25 to +55°C (-13 to +131°F)
Storage Temperature: -40 to +70°C (-40 to +158°F)
Environment: RoHS
